Receive the command to switch on the position lights

PhysicalFunction

eVectors > eVectors > Physical Architecture > Physical Functions > Root Physical Function > Make the vehicle visible > Receive the command to switch on the position lights

Command symbol :

Allocating Component

Position lights UI

Incoming Functional Ports

FIP 1

Outgoing Functional Ports

FOP 1

Incoming Functional Exchanges

Exchange	Involving functional chains	Allocating component Exchanges	Distant Port	Source	Description	Allocated Exchange Items	Realized Functional Exchange	Realizing Functional Exchange
position lights on/off			FOP 1	Control position lights activation

Outgoing Functional Exchanges

Exchange	Involving functional chains	Allocating component Exchanges	Distant Port	Target	Description	Allocated Exchange Items	Realized Functional Exchange	Realizing Functional Exchange
position lights on/off			FIP 1	Control position lights and position lights indicator

Diagrams displaying "Receive the command to switch on the position lights"
